Entel DN495

Entel DN495

DN400 radios are rugged business critical two-way radios that provide the features of DMR Tier-2 / Tier-3 radio systems but without the associated complexity, restrictions/limitations and high infrastructure costs. DN400 radios work just like regular two-way radios but instead roam multiple LTE Cellular networks as well as using Wi-Fi networks so can cover anything from local to national / multi national coverage. Entel’s ‘simple to sophisticated’ range of DN400 radios have been designed to cover applications ranging from basic, e.g. a simple PTT all-call through to the most demanding of requirements.

  • Rugged, Submersible, Two-Way Radio with exceptionally loud audio
  • Long battery endurance
  • Dedicated PTT button
  • Dedicated Emergency button
  • Programmable feature buttons
  • Always available, quick and easy to use (no need to unlock device first)
  • Rapid drop-in charger
  • Can instantly swap a flat battery with a fully charged battery

Frequencies, Standards & Approvals

Frequency Bands
DN495 – EMEA, Korea, Thailand, India
LTE FDD: B1/B3/B5/B7/B8/B20
LTE TDD: B38/B40
WCDMA: B1/B5/B8
GSM: 850/900/1800/1900MHz
2.4G/5.8G 802.11 a/b/g/n*
Other band variants available on request
* 5.8GHz variant on request
Wi-Fi
2.4GHz / 5.8GHz 802.11 a/b/g/n*
* 5.8GHz variant on request
Bluetooth
BT2.1+EDR / 3.0 / 4.1LE
Satellite positioning
GPS / GLONASS / BeiDou (BDS)
Encryption
AES256
Dust & Liquid protection
IP68 (2 metres for 4 hours fully submersible)
Shock & Vibration, Drop test, Packing test
MIL-STD-810 C/D/E/F/G
ESD
IEC 61000-4-2
Approvals
Please see: www.entel.co.uk/red

General

Channel capacity
Virtually unlimited
Contact list
>1000
Audio Output
3-Watts RMS (internal & external speaker)
Microphone
Echo cancellation & Noise reduction
Dimensions
97mm X 59.5mm X 33mm (with CNB420E battery)
97mm X 59.5mm X 37mm (with CNB450E battery)
Weight
243g (with CNB420E battery)
267g (with CNB450E battery)
Battery, Capacity / Chemistry / Endurance (5/5/90)
CNB420E – 1350mAh – Li-Ion – 16 Hours
CNB450E – 2000mAh – Li-Ion – 23 Hours
SIM Card slot
Nano (4FF) Entel’s SIM is internal to the radio
Operating Temperature
-20 to +60°C
Storage Temperature
-30 to +75°C
